About Plan # 107-1196

About Plan # 107-1196

5642 SQUARE FEET 5 BEDROOMS 5 FULL BATH 2 HALF BATH
2 FLOOR 69' 8" WIDTH 106' 8" DEPTH 3 GARAGE BAY

Luxury House Plan features include concrete-block exterior construction; covered entry with round columns to French doors; foyer with coffered ceiling open to dining and living rooms as well as library; round columns to living room with fireplace and open to upper floor; dining room with coffered ceiling; kitchen with island and walk-in pantry and open to cafe; family room with coffered ceiling and access to rear covered patio bedroom 2 with private bath and access to rear patio library with coffered ceiling; upper floor master suite with coffered ceiling; two walk-in closets and private balcony master bath with whirlpool tub, corner shower, and split vanities; vestibule to loft with private balcony; Bedrooms 3, 4, and 5 with private baths and walk-in closets; play room

Each plan set includes the following:

  • Floor plan
  • Kitchen & Bath layout
  • Exterior elevations
  • Sections
  • Structural plans
  • Foundation plan
  • Roof plan
  • Mechanical layout
  • Electrical layout

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required.
  • Site Plan - handled locally when required.
  • Mechanical Drawings (location of heating and air equipment and ductwork) - your subcontractors handle this.
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this.
  • Energy calculations - handled locally when required.

Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #107-1196 Floor Plan First Story - main level Floor Plan First Story of Coastal Plan #107-1196
#107-1196 Floor Plan Second Story - second floor Floor Plan Second Story of Coastal Plan #107-1196
Home Plan: #107-1196 Floor Plan First Story - main level Floor Plan First Story of Coastal Plan #107-1196
#107-1196 Floor Plan Second Story - second floor Floor Plan Second Story of Coastal Plan #107-1196
Special Offer

Order a Cost-to-Build Report and get $100 off a plan priced $500 or more!

To get started, click the “Order a Cost-to-Build Report” button above; then on the next page, click “Order Now and Get $100 Coupon” for your promo code.

Additional specs and features

Summary Information

Plan #:
# 107-1196
Floors:
2
Bedrooms:
5
Full Baths:
5
Half Baths:
2

Square Footage

Heated Sq Feet:
5642
Main Floor:
2882
Upper Floor:
2760
Unfinished Sq Ft:
Garage :
1145

Dimensions

Width:
69' 8"
Depth:
106' 8"

Architectural Styles

Mediterranean
Luxury
Coastal
Spanish

Exterior Wall Material

Stucco

Roofing Material

Tiles

Ceiling Height

9 Foot Ceiling

Special Feature

Mother in law apartment
Fireplace
Dining Room
Family Room
Game Room
Main Level Laundry
Library
Media Room
Color Photos
Loft
Split Bathroom

Garage Type

Attached Garage
Courtyard Entry

Exterior Wall Framing

Concrete

Building Lot Type

View Lot

Kitchen Features

Kitchen Island
Walk-in Pantry
Peninsula/Eating Bar

Porches and Exterior Features

Courtyard
Covered Front Porch
Covered Rear Porch

Master Suite Features

Master Bathroom
Walk In Closet
Private Deck
Second Floor Master

PRICING OPTIONS

A full set of construction drawings in digital PDF format emailed to you. Comes with a license to build one home. PDF includes copyright release to make modifications (only minor nonstructural recommended); print as many sets as you need.

For use by design professionals, this set contains all of the CAD files for your home and will be emailed to you. Comes with a license to build one home. Recommended if making major modifications to your plans.
