About Plan # 133-1005

About Plan # 133-1005

4050 SQUARE FEET 3 BEDROOMS 3 FULL BATH 2 HALF BATH
2 FLOOR 39' 8" WIDTH 85' 10" DEPTH 2 GARAGE BAY

With its symmetrically designed exterior, achieved effortless with the placement of the twin garages, balconies and chimneys, the Monte Carlo house plan is perfect for your narrow lot. The volume ceiling in the great room allows a peek from the upstairs spaces, creating a wide-open feel. The great room directly accesses the lanai of this narrow house plan, which features a pool, spa and convenient summer kitchen. The island kitchen offers casual dining at the eating bar and in the dinette, but also serves the formal dining area just steps away. The huge master suite, located upstairs but separate from the other bedrooms and close to the breakfast bar, includes walk-in closets, dual sinks, large shower, soaking tub and access to its own private covered lanai and sundeck. Monte Carlo house plan is pure perfection for a lavish lifestyle and is a perfect narrow house plan for your narrow lot.

Each plan set includes the following:

  • FLOOR PLAN: Showing all dimensions, window and door locations, laminated beams, columns, floor materials, ceiling heights, fireplace size, and specifications.
  • FOUNDATION PLAN: Dimensioned plan detailing the location and size of footings, slabs, reinforcing steel, and other structural elements that are required to support the load of the upper floors.
  • ROOF PLAN: Dimensioned plan showing the elements that make up the roof, including notation of spacing and schematics of peaks and valleys.
  • ELECTRICAL LAYOUT: Specifications, notes, schedules, and plan defining the location of panels, service, lighting fixtures, switches, outlets, fans, etc. NOTE – PLEASE VERIFY
  • FRONT, REAR, AND SIDE ELEVATIONS: The front, rear, and side elevations of the house as drawn. Shows placement of doors & windows on exterior of house, as well as roof pitches, ridge heights, and locations of chimney, exterior vents, etc. The elevations show the positioning of the final grade of the lot, exterior finishes, and other details that are necessary to give the home exterior architectural styling.
  • CROSS SECTIONS AND INTERIOR DETAILS: Explain certain special conditions more appropriately. A cross section is basically a view of the home (or parts of the home) if it were sliced down the center. These details can be helpful for the contractor.

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required.
  • Site Plan - handled locally when required.
  • Mechanical Drawings (location of heating and air equipment and ductwork) - your subcontractors handle this.
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this.
  • Energy calculations - handled locally when required.




Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #133-1005 Floor Plan First Story - first story Floor Plan First Story of Spanish Plan #133-1005
Home Plan: #133-1005 Floor Plan First Story - first story Floor Plan First Story of Spanish Plan #133-1005
