About Plan # 175-1040

About Plan # 175-1040

6771 SQUARE FEET 5 BEDROOMS 5 FULL BATH 0 HALF BATH
2 FLOOR 127' 0" WIDTH 120' 8" DEPTH 3 GARAGE BAY

Over 6500 square feet for these Luxury House Plans are spread across 5 bedrooms, 5.5 baths and a three-car garage in the Escada House Plan. The master suite is a picture of splendor, with huge walk-in closets and a spacious master bath. The grand entranceway, the wet bar in the living room, library and the rear veranda add unique touches--while the kitchen with island and pantry--and plenty of extra storage add practicality. The home plan is finished with a beautiful covered lanai accessible from the family room, living room and master suite. This is definately a must have set of Mediterranean house plans!

Each plan set includes the following:

  • Elevations
  • Floor Plans
  • Building Section Markers
  • Electrical Layout
  • Slab Plan
  • Roof Plan
  • Building Sections
  • Typical Wall Sections
  • Miscellaneous Notes & Details



Not Included with the Plan:

  • NO MEPs, NO Framing,
  • No Trusses: The client gets that from the truss manufacturer
  • No Engineering, You will need to get the plans stamped and engineered locally
  • HVAC and Plumbing is not included




Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #175-1040 Floor Plan First Story - main Floor Plan First Story of Coastal Plan #175-1040
Home Plan: #175-1040 Floor Plan First Story - main Floor Plan First Story of Coastal Plan #175-1040
Special Offer

Order a Cost-to-Build Report and get $100 off a plan priced $500 or more!

To get started, click the “Order a Cost-to-Build Report” button above; then on the next page, click “Order Now and Get $100 Coupon” for your promo code.

Additional specs and features

Summary Information

Plan #:
# 175-1040
Floors:
2
Bedrooms:
5
Full Baths:
5

Square Footage

Heated Sq Feet:
6771
Main Floor:
4791
Upper Floor:
1980
Unfinished Sq Ft:

Dimensions

Width:
127' 0"
Depth:
120' 8"
Ridge Height:
29-8' 0"

Architectural Styles

Mediterranean
Southwest
Luxury
Coastal
Concrete Block/ ICF Design

Exterior Wall Material

Stucco

Roofing Material

Tiles

Roof Pitch

6/12

Ceiling Height

10 Foot Ceiling

Special Feature

Dining Room
Home Office
Bonus Room
Family Room
Main Level Laundry
Library
Loft
Storage
Den
Vaulted Ceilings
Balcony

Garage Type

Attached Garage
Courtyard Entry
Front Entry

Exterior Wall Framing

Concrete

Building Lot Type

View Lot

Kitchen Features

Kitchen Island
Nook/Breakfast Area
Walk-in Pantry
Peninsula/Eating Bar

Porches and Exterior Features

Courtyard
Covered Rear Porch
Screened in Lanai
Covered Lanai

Master Suite Features

Main Floor Master
Master Bathroom
Walk In Closet

Additional Notes from Designer

PLEASE NOTE: This designer has zip code restrictions and a 5-7 day processing time for their CAD and PDF orders. Please contact us to verify your zip code BEFORE you order!! 2x6 and Right-Reading Reverse options are available. PLEASE NOTE: The designer is currently not providing modifications. We suggest you purchase a CAD file and work with a local engineer for changes. Additionally, orders (including electronic formats) could take up to 5 days to be delivered or shipped. Thank you!
