1-Bedroom, 3508 Sq Ft Coastal Plan with Master Bathroom

This image shows the front elevation for these Mediterranean House Plans.
1-Bedroom, 3508 Sq Ft Coastal House Plan - 175-1077 - Front Exterior

About Plan # 175-1077

About Plan # 175-1077

3508 SQUARE FEET 1 BEDROOMS 0 FULL BATH 0 HALF BATH
1 FLOOR 75' 0" WIDTH 104' 10" DEPTH 0 GARAGE BAY

This home plan has striking curb appeal with its well-balanced and detailed Mediterranean facade. The floor plan offers open, formal and casual living areas. Plenty of natural light and views to spacious outdoor areas are provided by the use of pocketing sliding-glass doors, French doors, windows, and mitered glass. This house plan offers three full bedrooms with four full baths. The family room features a built-in entertainment center and is easily furnished. The functional and spacious kitchen is open to the family room and dinette. This plan is not for sale for use in Collier County, Florida or Lee County, Florida without the consent of the designer. Please contact us if you want to build this plan in those areas. Concrete block exterior construction

Each plan set includes the following:

  • FLOOR PLAN: Showing all dimensions, window and door locations, laminated beams, columns, floor materials, ceiling heights, fireplace size (if applicable), and specifications.
  • FOUNDATION PLAN: Dimensioned plan detailing the location and size of footings, slabs, reinforcing steel, and other structural elements that are required to support the load of the upper floors.
  • ROOF PLAN: Dimensioned plan showing the elements that make up the roof, including notation of spacing and schematics of peaks and valleys.
  • ELECTRICAL LAYOUT: Specifications, notes, schedules, and plan defining the location of panels, service, lighting fixtures, switches, outlets, fans, etc. NOTE – PLEASE VERIFY
  • FRONT, REAR, AND SIDE ELEVATIONS: The front, rear, and side elevations of the house as drawn. Shows placement of doors & windows on exterior of house, as well as roof pitches, ridge heights, and locations of chimney, exterior vents, etc. The elevations show the positioning of the final grade of the lot, exterior finishes, and other details that are necessary to give the home exterior architectural styling.
  • CROSS SECTIONS AND INTERIOR DETAILS: Explain certain special conditions more appropriately. A cross section is basically a view of the home (or parts of the home) if it were sliced down the center. Typical wall sections are also included. These details can be helpful for the contractor.

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required.
  • Site Plan - handled locally when required.
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this.
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this.
  • Energy calculations - handled locally when required.




Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #175-1077 Floor Plan First Story - first story Floor Plan First Story of Coastal Plan #175-1077
Home Plan: #175-1077 Floor Plan First Story - first story Floor Plan First Story of Coastal Plan #175-1077
