Front elevation of Mediterranean home (ThePlanCollection: House Plan #175-1066)
5-Bedroom, 7123 Sq Ft Mediterranean House Plan - 175-1066 - Front Exterior

About Plan # 175-1066

About Plan # 175-1066

7123 SQUARE FEET 5 BEDROOMS 6 FULL BATH 1 HALF BATH
2 FLOOR 102' 0" WIDTH 132' 10" DEPTH 4 GARAGE BAY

Luxury Homeplans WDG-F2-7123 are 5-bedroom elegant estate with an old-world feel. The large mahogany double doors open to a grand foyer with an elegant circular stairway. Just past the foyer is a colonnade and a large rotunda living room with a double sided wet bar, fireplace and a panoramic glass wall with luxurious French doors. Towards the master bedroom side is a large library, with built in bookshelves. This side of the house also has an exercise room with a built-in wet bar, stereo and drinking fountain. The master suite features a sitting area, built-in entertainment and lanai access. The large master bath has both a circular spa and a circular walk-in shower. There is also a pair of double French doors in the master bath that open to a small balcony overlooking a private garden with tropical landscaping and beautiful koi pond. The other side of these Mediterranean house plans has an oval shaped dining room that rests over a large fountain that can be seen through the tall glass windows. Around the corner is a bedroom with private access suite overlooking a tropical landscape garden and koi pond. The family room features a diamond shaped ceiling with exposed wood beams. The family room views a stunning tropical landscaping scene surrounding a large swimming pool with a disappearing edge. This Luxury home plans second level offers a gallery bridge over the foyer leading to three other bedroom suites. One of the bedroom suites has an access to the large sun deck while the other bedrooms access the sundeck through the theatre room.

Each plan set includes the following:

  • Elevations
  • Floor Plans
  • Building Section Markers
  • Electrical Layout
  • Slab Plan
  • Roof Plan
  • Building Sections
  • Typical Wall Sections
  • Miscellaneous Notes & Details



Not Included with the Plan:

  • NO MEPs, NO Framing,
  • No Trusses: The client gets that from the truss manufacturer
  • No Engineering, You will need to get the plans stamped and engineered locally
  • HVAC and Plumbing is not included




Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #175-1066 Floor Plan First Story - s Floor Plan First Story of Coastal Plan #175-1066
Home Plan: #175-1066 Floor Plan First Story - s Floor Plan First Story of Coastal Plan #175-1066
Special Offer

Order a Cost-to-Build Report and get $100 off a plan priced $500 or more!

To get started, click the “Order a Cost-to-Build Report” button above; then on the next page, click “Order Now and Get $100 Coupon” for your promo code.

Additional specs and features

Summary Information

Plan #:
# 175-1066
Floors:
2
Bedrooms:
5
Full Baths:
6
Half Baths:
1

Square Footage

Heated Sq Feet:
7123
Main Floor:
5225
Upper Floor:
1898
Unfinished Sq Ft:

Dimensions

Width:
102' 0"
Depth:
132' 10"
Ridge Height:
34-5' 0"

Architectural Styles

Mediterranean
Southwest
Luxury
Coastal
Spanish
Concrete Block/ ICF Design
California Style
Florida Style
Handicap Accessible

Exterior Wall Material

Stucco

Roofing Material

Tiles

Roof Pitch

5/12

Ceiling Height

10 Foot Ceiling

Special Feature

In Home Gym
Fireplace
Swimming Pool
Dining Room
Home Office
Family Room
Main Level Laundry
Library
Home Theater
Loft
Split Bathroom
Vaulted Ceilings
Balcony

Garage Type

Attached Garage
Courtyard Entry

Exterior Wall Framing

Concrete

Building Lot Type

View Lot

Kitchen Features

Kitchen Island
Butler's Pantry
Nook/Breakfast Area
Outdoor Kitchen
Peninsula/Eating Bar

Porches and Exterior Features

Breezeway
Courtyard
Covered Front Porch
Covered Rear Porch
Friend's Entry
Sundeck
Screened in Lanai
Covered Lanai

Master Suite Features

Main Floor Master
Master Bathroom
Walk In Closet
Sitting Area

Additional Notes from Designer

PLEASE NOTE: This designer has zip code restrictions and a 5-7 day processing time for their CAD and PDF orders. Please contact us to verify your zip code BEFORE you order!! 2x6 and Right-Reading Reverse options are available. PLEASE NOTE: The designer is currently not providing modifications. We suggest you purchase a CAD file and work with a local engineer for changes. Additionally, orders (including electronic formats) could take up to 5 days to be delivered or shipped. Thank you!

PRICING OPTIONS

For use by design professionals, this set contains all of the CAD files for your home and will be emailed to you. Comes with a license to build one home. Recommended if making major modifications to your plans.

A full set of construction drawings in digital PDF format emailed to you. Comes with a license to build one home. PDF includes copyright release to make modifications (only minor nonstructural recommended); print as many sets as you need.

A full set of construction drawings printed on a reproducible medium. Allows you to make as many copies as needed. Includes license to build one home and a copyright release to make as many modifications as you see fit. Delivered by mail.

ADDITIONAL INFORMATION

All sales of house plans, modifications, and other products found on this site are final. No refunds or exchanges can be given once your order has begun the fulfillment process. Please see our Policies for additional information.

All plans offered on ThePlanCollection.com are designed to conform to the local building codes when and where the original plan was drawn.

The homes as shown in photographs and renderings may differ from the actual blueprints. For more detailed information, please review the floor plan images herein carefully.
