4-Bedroom, 4392 Sq Ft Coastal Plan with Nook/Breakfast Area

This image shows the courtyard entry for these Luxury Plans, Mediterranean Home Plans, Florida Designs.
4-Bedroom, 4392 Sq Ft Coastal House Plan - 175-1062 - Front Exterior

About Plan # 175-1062

About Plan # 175-1062

4392 SQUARE FEET 4 BEDROOMS 4 FULL BATH 0 HALF BATH
2 FLOOR 92' 2" WIDTH 135' 0" DEPTH 3 GARAGE BAY

This design is a beautiful Florida two-story home with a unique Mediterranean curb appeal. This home is best appointed for properties with panoramic views from the rear yard. The entire back of this home can be opened up by large expanses of zero corner pocket sliding glass doors, protected by a large covered lanai, which spans across the entire rear of the home. The Mediterranean lanai also features a sports bar and grill. This home plan has a perfect flow for large family and friend gatherings with a large walk-in wet bar centrally located. This plan is not for sale for use in Collier County, Florida or Lee County, Florida without the consent of the designer. Please contact us if you want to build this Mediterranean plan in those areas. Concrete block exterior construction

Each plan set includes the following:

  • Elevations
  • Floor Plans
  • Building Section Markers
  • Electrical Layout
  • Slab Plan
  • Roof Plan
  • Building Sections
  • Typical Wall Sections
  • Miscellaneous Notes & Details



Not Included with the Plan:

  • NO MEPs, NO Framing,
  • No Trusses: The client gets that from the truss manufacturer
  • No Engineering, You will need to get the plans stamped and engineered locally
  • HVAC and Plumbing is not included




Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #175-1062 Floor Plan First Story - first story Floor Plan First Story of Coastal Plan #175-1062
Home Plan: #175-1062 Floor Plan First Story - first story Floor Plan First Story of Coastal Plan #175-1062
Special Offer

Order a Cost-to-Build Report and get $100 off a plan priced $500 or more!

To get started, click the “Order a Cost-to-Build Report” button above; then on the next page, click “Order Now and Get $100 Coupon” for your promo code.

Additional specs and features

Summary Information

Plan #:
# 175-1062
Floors:
2
Bedrooms:
4
Full Baths:
4

Square Footage

Heated Sq Feet:
4392
Main Floor:
3656
Upper Floor:
736
Unfinished Sq Ft:
Garage :
1121

Dimensions

Width:
92' 2"
Depth:
135' 0"
Ridge Height:
32' 0"

Architectural Styles

Mediterranean
Luxury
Beachfront
Coastal
Spanish
Concrete Block/ ICF Design

Exterior Wall Material

Stucco

Roofing Material

Tiles

Roof Pitch

6/12

Ceiling Height

10 Foot Ceiling
9 Foot Ceiling

Special Feature

Dining Room
Home Office
Family Room
Main Level Laundry
Split Bathroom
Den
Vaulted Ceilings
Balcony

Garage Type

Attached Garage
Courtyard Entry

Kitchen Features

Kitchen Island
Nook/Breakfast Area
Peninsula/Eating Bar

Porches and Exterior Features

Courtyard
Covered Rear Porch
Screened in Lanai
Covered Lanai

Master Suite Features

Main Floor Master
Master Bathroom
Walk In Closet

Additional Notes from Designer

PLEASE NOTE: This designer has zip code restrictions and a 5-7 day processing time for their CAD and PDF orders. Please contact us to verify your zip code BEFORE you order!! 2x6 and Right-Reading Reverse options are available. PLEASE NOTE: The designer is currently not providing modifications. We suggest you purchase a CAD file and work with a local engineer for changes. Additionally, orders (including electronic formats) could take up to 5 days to be delivered or shipped. Thank you!

PRICING OPTIONS

For use by design professionals, this set contains all of the CAD files for your home and will be emailed to you. Comes with a license to build one home. Recommended if making major modifications to your plans.

A full set of construction drawings in digital PDF format emailed to you. Comes with a license to build one home. PDF includes copyright release to make modifications (only minor nonstructural recommended); print as many sets as you need.

A full set of construction drawings printed on a reproducible medium. Allows you to make as many copies as needed. Includes license to build one home and a copyright release to make as many modifications as you see fit. Delivered by mail.

ADDITIONAL INFORMATION

All sales of house plans, modifications, and other products found on this site are final. No refunds or exchanges can be given once your order has begun the fulfillment process. Please see our Policies for additional information.

All plans offered on ThePlanCollection.com are designed to conform to the local building codes when and where the original plan was drawn.

The homes as shown in photographs and renderings may differ from the actual blueprints. For more detailed information, please review the floor plan images herein carefully.
