House Plan # 101-1127

Best Price Guaranteed

Floors: 1
Living Sq Feet: 5282
Bedrooms: 5
Full Baths: 3
Half Baths: 0
Garage Bays: 3
Width: 95' 0"
Depth: 62' 0"
ADD TO CART

View All Price Options

Ask a Question

  pinit     Houzz   ShareThis


HOUSE PLAN DESCRIPTION
Mediterranean elegance shapes the facade of this tempting design. A formal dining room and den flank the entry inside and an elegant curved-stairway leads to the lower level. The snack-bar kitchen, breakfast nook bay and hearth rooms are open to one another for casual family gatherings, while the wrap-around deck outside makes it a fantastic area for viewing the back yard. The main-level master suite boasts a private wood deck, master bath and roomy walk-in closet. The basement level offers four additional bedrooms, three bathrooms, a family room, a toy room and exercise room.
Reverse Plan Images
FLOOR PLANS
Home Plan : # 101-1127 MAIN FLOOR PLAN
MAIN FLOOR PLAN
Copyright held by designer.

Home Plan : # 101-1127 BASEMENT FLOOR PLAN
BASEMENT FLOOR PLAN
Copyright held by designer.

PLAN SPECS & FEATURES

Summary Information
House Plan: #101-1127
Floors: 1
Bedrooms: 5
Full Baths: 3
Half Baths: 0
Garage Bays: 3
DIMENSIONS
Width: 95' 0"
Depth: 62' 0"
SQUARE FOOTAGE
Heated Sq Feet: 5282
Main Floor: 2812
Lower Floor: 2470


Architectural Styles
Ranch
Contemporary

Ceiling Height
10 Foot Ceiling

Framing
Exterior Wall Framing:    2x6

Exterior Wall Material
Stucco

Garage Type
Attached Garage

Roof Pitch
6/12

Special Feature
Dining Room
Family Room


PRICING OPTIONS

ADD TO CART

You can select your plan package and options once the plan has been added to the cart

Plan Package and Pricing Help
PLAN PACKAGES: HOUSE PLAN # 101-1127
CAD File $3222.02
Minimum Construction Package (5 Sets) $1637.42
PDF File Set $2271.26
Reproducible Master $2059.98
Standard Construction Package (8 Sets) $1743.06
Study Set (Construction Bid Set) $1531.78
FOUNDATION OPTIONS
Crawlspace $295.00
Slab $295.00
Daylight Basement $0.00
OTHER OPTIONS / ADD-ONS
Right Reading Reverse $295.00
Mirror Reverse $55.00
Additional Set(s), Each $50.00
