House Plan #160-1002
Plan Name: 160-1002   Bedrooms: 5   Width: 36' 0"
Square Feet: 1662 Sq Ft.   Bathrooms: Full Baths: 3
Half Baths: 0
  Depth: 50' 6"
Floors: 2   Garage Bays: 0 Ridge Height: 25'
House Plan Main Image House Plan Pricing
Image not available.
CONSTRUCTION SETS
  Minimum Construction Package (5 Sets) $575.00
  Standard Construction Package (8 Sets) $625.00
  PDF File Set $775.00
  Reproducible Master $775.00
  CAD File $975.00
  Study Set (Construction Bid Set) $525.00
FOUNDATION OPTIONS
  Basement $0.00
  Daylight Basement $0.00
OTHER OPTIONS / ADD-ONS
  Right Reading Reverse $175.00
  Materials List $70.00
  Additional Set(s), Each $55.00
Square Footage House Plan Description
Heated Sq Ft: 1662
Main Floor: 976
Upper Floor: 686
Unfinished Sq ft

The Great room in this narrow lot cottage design redefines the terms; open floor plan, versatile and spaciousness with its twenty-three foot clear span width and partial vaulted ceiling. The side screened porch area adjacent to the kitchen, the partially rear cover deck and rear open sundeck ensures ongoing individual or group activities regardless of the weather or local resident insect life intrusions. I have given the Great Room staircase the moniker a square spiral staircase, having all the great attributes of a spiral staircase but having none of the tight restrictiveness and limited furniture access usually associated with one. The two second floor bedrooms with ten and twelve foot ceilings and private covered balcony bring a soothing airiness to this vaulted level. Daylight basement plan contains two additional bedrooms, shared bathroom and multipurpose recreation room with patio access. The separate private entrance easily transforms this level into a home office or business space.

Home Features
  Architectural Styles
Craftsman
Log Cabin

  Building Lot Type
Flat Site

  Ceiling Height
8 Foot Ceiling

  Exterior Wall Framing
2x6

  Fireplaces
One Fireplace

  Kitchen Features
Eat-In Kitchen
Nook/Breakfast Area
Peninsula/Eating Bar

  Master Suite Features
Master Bathroom
Private Deck
Second Floor Master

  Porches and Exterior Features
Covered Front Porch
Covered Rear Porch
Sundeck
Screened Porch/Sunroom

  Roof Pitch
12/12
6/12

  Special Feature
Split Bathroom
Fireplace
Main Level Laundry
Balcony
Storage
Vaulted Ceilings

House Plan : 160-1002 Images
Reverse Plan Images
   House Plan #160-1002
Image not available.
  Home Plan: 160-1002 Floor Plan First Story
Floor Plan First Story
  Home Plan: 160-1002 Floor Plan Second Story
Floor Plan Second Story
