Front elevation of Garage w/Apartments home (ThePlanCollection: House Plan #100-1055)
2-Car Garage with 556 Sq Ft Studio Apartment Plan - 100-1055 - Main Exterior

About Plan # 100-1055

About Plan # 100-1055

556 SQUARE FEET 0 BEDROOMS 1 FULL BATH 0 HALF BATH
2 FLOOR 31' 4" WIDTH 33' 4" DEPTH 2 GARAGE BAY

Here is a perfect detached garage with open studio above. Use your imagination when finishing this vaulted space. It would work well as an in-law suite, a home office, or a rental property. The flexible styling will fit most craftsman, lodge, and shingle style homes.

Each plan set includes the following:

  • Cover Sheet: Shows the front elevation and typical notes and requirements.
  • Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
  • Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
  • Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible
  • Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
  • Roof Plan
  • Typical wall section
  • Typical stair section
  • Cabinets are shown on all plans.



These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required.
  • Site Plan - handled locally when required.
  • Mechanical Drawings (location of heating and air equipment and ductwork) - your subcontractors handle this.
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this.
  • Energy calculations - handled locally when required.

Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #100-1055 Floor Plan First Story - first story Floor Plan First Story of Garage w/Apartments Plan #100-1055
#100-1055 Floor Plan Second Story - second story Floor Plan Second Story of Garage w/Apartments Plan #100-1055
Home Plan: #100-1055 Floor Plan First Story - first story Floor Plan First Story of Garage w/Apartments Plan #100-1055
#100-1055 Floor Plan Second Story - second story Floor Plan Second Story of Garage w/Apartments Plan #100-1055
Special Offer

Order a Cost-to-Build Report and get $100 off a plan priced $500 or more!

To get started, click the “Order a Cost-to-Build Report” button above; then on the next page, click “Order Now and Get $100 Coupon” for your promo code.

Additional specs and features

Summary Information

Plan #:
# 100-1055
Floors:
2
Full Baths:
1
Garage :
2

Square Footage

Heated Sq Feet:
556
Upper Floor:
556
Unfinished Sq Ft:
Main Floor:
1014

Dimensions

Width:
31' 4"
Depth:
33' 4"
Ridge Height:
24' 0"

Architectural Styles

Country
Garage
Traditional
Craftsman
Garage w/Apartments
In-Law Suite

Exterior Wall Material

Rock/Stone
Shakes

Roofing Type

Gable/Dormer

Roofing Material

Asphalt Shingles

Roof Pitch

9/12

Ceiling Height

9 Foot Ceiling

Special Feature

Vaulted Ceilings
Balcony
Second Level Laundry
Open Floor Plan

Garage Type

Attached Garage
Front Entry

Exterior Wall Framing

2x4

Building Lot Type

Narrow Lot Design

Kitchen Features

Kitchen Island
Eat-In Kitchen

Additional Notes from Designer

The CAD File formats are drawn in SoftPlan. PLEASE NOTE: Plans by this designer do NOT come with FRAMING! This designer does not do ICF.
