About Plan # 160-1023

About Plan # 160-1023

1058 SQUARE FEET 0 BEDROOMS 0 FULL BATH 0 HALF BATH
2 FLOOR 30' 0" WIDTH 25' 0" DEPTH 2 GARAGE BAY

The spacious open workshop and volume ceiling accommodates everyone from the hobby enthusiast up to the energetic rock wall climber. The oversized garage depth easily handles larger vehicles or incorporate a full width workbench to create additional storage space. The second level unfinished storage loft is presently accessed by a ladder. Add a staircase to transform this bonus area into a quaint home office or exercise room retreat enhanced with a large view dormer and generous window openings.

Each plan set includes the following:

  • Cover sheet with rendering and art floor plans.
  • General notes and specifications.
  • Foundation plan
  • Main floor plan
  • Second-floor plan (if applicable)
  • Structural floor/Roof information
  • Electrical layout
  • Minimum of two cross-sections Details
  • Exterior Elevations Generic detail sheet

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required.
  • Site Plan - handled locally when required.
  • Mechanical Drawings (location of heating and air equipment and ductwork) - your subcontractors handle this.
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this.
  • Energy calculations - handled locally when required.




Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #160-1023 Floor Plan First Story - first story Floor Plan First Story of Garage w/Apartments Plan #160-1023
#160-1023 Floor Plan Second Story - second story Floor Plan Second Story of Garage w/Apartments Plan #160-1023
Home Plan: #160-1023 Floor Plan First Story - first story Floor Plan First Story of Garage w/Apartments Plan #160-1023
#160-1023 Floor Plan Second Story - second story Floor Plan Second Story of Garage w/Apartments Plan #160-1023
Special Offer

Order a Cost-to-Build Report and get $100 off a plan priced $500 or more!

To get started, click the “Order a Cost-to-Build Report” button above; then on the next page, click “Order Now and Get $100 Coupon” for your promo code.

Additional specs and features

Summary Information

Plan #:
# 160-1023
Floors:
2

Square Footage

Heated Sq Feet:
1058
Main Floor:
700
Upper Floor:
358
