5-Bedroom, 4978 Sq Ft Luxury Home Plan - 175-1019 - Main Exterior

About Plan # 175-1019

About Plan # 175-1019

4978 SQUARE FEET 5 BEDROOMS 5 FULL BATH 1 HALF BATH
2 FLOOR 94' 0" WIDTH 70' 1" DEPTH 3 GARAGE BAY

This design is an eye-catching Mediterranean home plan designed for a rear-view oriented homesite with pocket doors and mitered glass allowing the home to be flooded with light. Upon entry from the foyer of this home plan, you will find a spacious dining room and a very large living room with a stone fireplace and a wall of glass allowing unobstructed views across the pool and out onto sunset bay views. These are just a few highlights that make this Meditteranean home plan prefect for living the intercoastal waterways.

Each plan set includes the following:

  • Elevations
  • Floor Plans
  • Building Section Markers
  • Electrical Layout
  • Slab Plan
  • Roof Plan
  • Building Sections
  • Typical Wall Sections
  • Miscellaneous Notes & Details



Not Included with the Plan:

  • NO MEPs, NO Framing,
  • No Trusses: The client gets that from the truss manufacturer
  • No Engineering, You will need to get the plans stamped and engineered locally
  • HVAC and Plumbing is not included




Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #175-1019 Floor Plan First Story - first story Floor Plan First Story of Luxury Plan #175-1019
