About Plan # 133-1059

About Plan # 133-1059

6924 SQUARE FEET 5 BEDROOMS 5 FULL BATH 0 HALF BATH
2 FLOOR 106' 8" WIDTH 164' 0" DEPTH 3 GARAGE BAY

Luxury Home plans have extreme elegance! Words best describe this home plan with its attractive, Mediterranean exterior and open, flowing floor plan. Beyond the grand foyer is the two-story formal living room with large mitered bow windows at the first and second floor levels providing a breathtaking view of the pool area and beyond. Also in the living room is a stone fireplace with arched openings on either side that lead to the formal dining room, which has French doors that open onto the rear lanai. A large gourmet kitchen opens to the dinette, and family room areas and easily serves the dining room through the butler's pantry/wet bar. The family room is the center of activity with built-in entertainment center and large pocketing, zero-corner sliding glass doors which, when open; make the massive lanai space and family room one. On the lanai is an outdoor two-sided fireplace and outdoor kitchen/bar. The spacious master suite has a built-in entertainment center and French doors opening to a private lanai. Off the master suite is a sitting room with a kitchenette and bayed window viewing the rear of the property. The second floor holds three full bedrooms, each with its own bath. An expansive loft overlooks the living room and exterior balcony beyond completes this house plan.

Each plan set includes the following:

  • FLOOR PLAN: Showing all dimensions, window and door locations, laminated beams, columns, floor materials, ceiling heights, fireplace size, and specifications.
  • FOUNDATION PLAN: Dimensioned plan detailing the location and size of footings, slabs, reinforcing steel, and other structural elements that are required to support the load of the upper floors.
  • ROOF PLAN: Dimensioned plan showing the elements that make up the roof, including notation of spacing and schematics of peaks and valleys.
  • ELECTRICAL LAYOUT: Specifications, notes, schedules, and plan defining the location of panels, service, lighting fixtures, switches, outlets, fans, etc. NOTE – PLEASE VERIFY
  • FRONT, REAR, AND SIDE ELEVATIONS: The front, rear, and side elevations of the house as drawn. Shows placement of doors & windows on exterior of house, as well as roof pitches, ridge heights, and locations of chimney, exterior vents, etc. The elevations show the positioning of the final grade of the lot, exterior finishes, and other details that are necessary to give the home exterior architectural styling.
  • CROSS SECTIONS AND INTERIOR DETAILS: Explain certain special conditions more appropriately. A cross section is basically a view of the home (or parts of the home) if it were sliced down the center. These details can be helpful for the contractor.

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required.
  • Site Plan - handled locally when required.
  • Mechanical Drawings (location of heating and air equipment and ductwork) - your subcontractors handle this.
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this.
  • Energy calculations - handled locally when required.




Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #133-1059 Floor Plan First Story - s Floor Plan First Story of Luxury Plan #133-1059
Home Plan: #133-1059 Floor Plan First Story - s Floor Plan First Story of Luxury Plan #133-1059
Special Offer

Order a Cost-to-Build Report and get $100 off a plan priced $500 or more!

To get started, click the “Order a Cost-to-Build Report” button above; then on the next page, click “Order Now and Get $100 Coupon” for your promo code.

Additional specs and features

Summary Information

Plan #:
# 133-1059
Floors:
2
Bedrooms:
5
Full Baths:
5
Garage :
3

Square Footage

Heated Sq Feet:
6924
Main Floor:
5400
Upper Floor:
1524
Unfinished Sq Ft:
Garage :
1249

Dimensions

Width:
106' 8"
Depth:
164' 0"
Ridge Height:
35' 9"

Architectural Styles

Mediterranean
Southwest
Luxury
Traditional
Spanish
Concrete Block/ ICF Design
California Style
Florida Style

Exterior Wall Material

Stucco

Roofing Type

Hip

Roofing Material

Tiles

Roof Pitch

6/12

Ceiling Height

10 Foot Ceiling

Special Feature

Dining Room
Home Office
Main Level Laundry
Split Bathroom
Den
Elevator

Garage Type

Attached Garage
Side Entry

Fireplaces

One Fireplace

Exterior Wall Framing

Concrete

Building Lot Type

Flat Site
Corner Lot

Kitchen Features

Butler's Pantry
Peninsula/Eating Bar

Porches and Exterior Features

Covered Front Porch
Covered Rear Porch
Friend's Entry
Covered Lanai

Master Suite Features

Main Floor Master
Master Bathroom
Walk In Closet
Sitting Area

Additional Notes from Designer

Please Note that the designer's office will be closed between 8/4/22 to 8/9/2022. Any orders placed during this time will be processed once the designer resumes office after 8/9-2022.

PRICING OPTIONS

For use by design professionals, this set contains all of the CAD files for your home and will be emailed to you. Comes with a license to build one home. Recommended if making major modifications to your plans.

A full set of construction drawings in digital PDF format emailed to you. Comes with a license to build one home. PDF includes copyright release to make modifications (only minor nonstructural recommended); print as many sets as you need.

ADDITIONAL INFORMATION

All sales of house plans, modifications, and other products found on this site are final. No refunds or exchanges can be given once your order has begun the fulfillment process. Please see our Policies for additional information.

All plans offered on ThePlanCollection.com are designed to conform to the local building codes when and where the original plan was drawn.

The homes as shown in photographs and renderings may differ from the actual blueprints. For more detailed information, please review the floor plan images herein carefully.
