House Plan #175-1036
Plan Name: 175-1036   Bedrooms: 4   Width: 40' 0"
Square Feet: 3763 Sq Ft.   Bathrooms: Full Baths: 3
Half Baths: 0
  Depth: 77' 2"
Floors: 3   Garage Bays: 4 Ridge Height: 40-4'
House Plan Main Image House Plan Pricing
Image not available.
  CAD File $2,000.00
  PDF File Set $2,000.00
  Reproducible Master $2,000.00
  Piling $0.00
  Right Reading Reverse $619.00
Square Footage House Plan Description
Heated Sq Ft: 3763
Main Floor: 2135
Upper Floor: 1628
Unfinished Sq ft

Stately Mediterranean house plan featuring three floors perfect for a coastal lot! Plenty of storage on the lower level of this floor plan and the added convenience of an elevator too. Upstairs of this home plan features your living and guest bedrooms, saving the entire third floor for the master suite. All together this blueprint offers 3,700 square feet of living plus the storage area downstairs. If you've got a waterfront lot, then this coastal house plan would be perfect to take in all of the views.

Home Features
  Architectural Styles
Florida Style
  Building Lot Type
Narrow Lot Design
Flat Site
  Ceiling Height
10 Foot Ceiling
11 Foot Ceiling
12 Foot Ceiling
  Exterior Wall Material
  Garage Type
Attached Garage
Under Main Floor Entry
Front Entry
  Kitchen Features
Eat-In Kitchen
Kitchen Island
Nook/Breakfast Area
Peninsula/Eating Bar
  Master Suite Features
Master Bathroom
Walk In Closet
Sitting Area
Second Floor Master
Private Deck
  Porches and Exterior Features
Covered Lanai
Covered Front Porch
Covered Rear Porch
  Roof Pitch
  Roofing Material
  Roofing Type
  Special Feature
Dining Room
Main Level Laundry
Split Bathroom
House Plan : 175-1036 Images
Reverse Plan Images
   House Plan #175-1036
Image not available.
  Home Plan: 175-1036 Floor Plan First Story
Floor Plan First Story
