2-Bedroom, 569 Sq Ft Garage Home Plan - 176-1017 - Main Exterior

About Plan # 176-1017

About Plan # 176-1017

569 SQUARE FEET 2 BEDROOMS 1 FULL BATH 0 HALF BATH
1 FLOOR 28' 0" WIDTH 28' 0" DEPTH 2 GARAGE BAY

Double garage with with living space above makes a great rental or guest suite. Plan comes complete with two options- build either the one or two bedroom version. Sloped ceilings create a cozy feeling. Efficient U-shaped kitchen is sure to please.

Each plan set includes the following:

  • Foundation plan
  • Exterior elevations
  • Floor plan(s)
  • Electrical layout
  • Cross section
  • Roof plan
  • Construction notes & details

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required.
  • Site Plan - handled locally when required.
  • Mechanical Drawings (location of heating and air equipment and ductwork) - your subcontractors handle this.
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this.
  • Energy calculations - handled locally when required.
