About Plan # 137-1428

About Plan # 137-1428

5024 SQUARE FEET 5 BEDROOMS 4 FULL BATH 0 HALF BATH
1 FLOOR 166' 0" WIDTH 94' 0" DEPTH 3 GARAGE BAY
Luxury Ranch home plan, with wrap around covered porch. The home includes features such as room in the garage for a workshop, a recreation room, guest room, den, and beautifully done master bedroom.

Each plan set includes the following:

  • All 4 elevations
  • Floor plan
  • Foundation plan
  • Sections
  • Interior elevations
  • Detail page

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required.
  • Site Plan - handled locally when required.
  • Mechanical Drawings (location of heating and air equipment and ductwork) - your subcontractors handle this.
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this.
  • Energy calculations - handled locally when required.




Write Your Own Review
Submit your changes for a FREE quote.
Submit your changes for a FREE quote.

FLOOR PLANS Flip Images

Home Plan: #137-1428 Floor Plan First Story - main Floor Plan First Story of Ranch Plan #137-1428
Home Plan: #137-1428 Floor Plan First Story - main Floor Plan First Story of Ranch Plan #137-1428
Special Offer

Order a Cost-to-Build Report and get $100 off a plan priced $500 or more!

To get started, click the “Order a Cost-to-Build Report” button above; then on the next page, click “Order Now and Get $100 Coupon” for your promo code.

Additional specs and features

Summary Information

Plan #:
# 137-1428
Floors:
1
Bedrooms:
5
Full Baths:
4

Square Footage

Heated Sq Feet:
5024
Main Floor:
5024
Unfinished Sq Ft:

Dimensions

Width:
166' 0"
Depth:
94' 0"
Ridge Height:
18' 0"

Architectural Styles

Ranch
Luxury

Exterior Wall Material

Stucco

Roofing Material

Metal

Roof Pitch

4/12

Special Feature

Guest Room

Garage Type

Front Entry

Fireplaces

Three Fireplaces

Exterior Wall Framing

2x6

Additional Notes from Designer

Plans from this designer could take up to 14 days to fulfill, regardless of the plan package that was ordered. Please Note: The plans by this designer DO NOT include electrical plans or electrical layout plans. PLEASE NOTE: For this designer, if you are ordering a CAD, the wait time could be 2-3 weeks, depending on the plan. If you need it sooner, please contact us to find out the wait time. Thank you!

PRICING OPTIONS

A full set of construction drawings in digital PDF format emailed to you. Comes with a license to build one home. PDF includes copyright release to make modifications (only minor nonstructural recommended); print as many sets as you need.

Five full printed sets with a license to build one home. This is the minimum number of sets you can build from.

Eight full printed sets with a license to build one home. Gives you extra sets needed for those using a general contractor.

A full set of construction drawings printed on a reproducible medium. Allows you to make as many copies as needed. Includes license to build one home and a copyright release to make as many modifications as you see fit. Delivered by mail.

For use by design professionals, this set contains all of the CAD files for your home and will be emailed to you. Comes with a license to build one home. Recommended if making major modifications to your plans.

Stamped "Not for Construction," this set allows you to review the home plan in detail and obtain bids. It is illegal to build a house from plans stamped this way and, due to copyright laws, they can not be copied.

ADDITIONAL INFORMATION

All sales of house plans, modifications, and other products found on this site are final. No refunds or exchanges can be given once your order has begun the fulfillment process. Please see our Policies for additional information.

All plans offered on ThePlanCollection.com are designed to conform to the local building codes when and where the original plan was drawn.

The homes as shown in photographs and renderings may differ from the actual blueprints. For more detailed information, please review the floor plan images herein carefully.
